WM4-96 Instruction manual: INDEX
CARLO GAVAZZI
WM4-96, 32-bit µ-processor based modular universal utili-
ty meter and power analyzer
FW rev.C.01
TO BEGIN WITH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
■ Front panel description . . . . . . . . . . . . . . . . . . . . .7
■ Display adjustment . . . . . . . . . . . . . . . . . . . . . . . .7
DISPLAYING OF THE VARIABLES . . . . . . . . . . . . . . . . .8
■ Page “00”, starting page . . . . . . . . . . . . . . . . . . . .8
■ How to scroll the display pages . . . . . . . . . . . . . . .9
■ How the F key changes function depending on . . . .
the display page . . . . . . . . . . . . . . . . . . . . . . . . . . .9
❏ Pages from “00” to “13”: displaying of the . . . .
variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
❏ Pages from “14” to “18”: displaying of the . . . .
MIN and MAX values . . . . . . . . . . . . . . . . . . .9
❏ Pages from “19” to “24”: displaying of the . . . .
harmonic analysis . . . . . . . . . . . . . . . . . . . . .10
❏ Displaying of the Energy Meters . . . . . . . . . .11
❏ Page “25”: displaying of the total energy . . . . .
meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
❏ Page “26”: displaying of partial energies . . . .10
❏ Page “27”: displaying of GAS and . . . . . . . . . . .
WATER meters . . . . . . . . . . . . . . . . . . . . . . .12
❏ Page “28” displaying of the instrument’s . . . . . .
configuration . . . . . . . . . . . . . . . . . . . . . . . . .12
❏ Displaying of the load profiles . . . . . . . . . . . .12
❏ Displaying with “pass code” access . . . . . . . .14
❏ Pass “1000”: displaying of recorded events . .14
❏ Pass “999”: storage of the consumed energy .15
❏ Pass “998”: displaying of recorded var dmd 16
