General specifications
Operating temperature: 0 to +50°C (32 to 122°F)
(R.H.< 90% non-condensing).
Storage temperature: -10 to +60°C (14 to 140°F)
(R.H. < 90% non-condensing).
Insulation reference voltage: 300 V
RMS
to ground (AV5
input).
Insulation: 4000 V
RMS
between all inputs / outputs to ground.
Dielectric strength: 4000 V
RMS
for 1 minute
Noise rejection: CMRR 100 dB, 48 to 62 Hz.
EMC: EN 50081-2, EN 50082-2.
Other standards: safety: IEC 61010-1, EN 61010-1.
Product: Energy measurements: EN61036, EN61268.
Pulse output: DIN43864.
Approvals: CE, UL, CSA.
Connector Screw-type
max. 2.5 mm 2 wires(2x1.5mm 2 ).
Housing
Dimensions 96x96x140 mm.
Material: ABS, self-extinguishing: UL 94 V-0.
Protection degree: front, IP65.
Weight: approx. 600 g (packing included).
■
Supply specifications
AC/DC voltage: 90 to 260V (standard)
18 to 60V (on request).
Energy consumption:
≤
30VA/12W (90 to 260V)
≤
20VA/12W (18 to 60V).
