| 53
Dimensioned Drawings | Zeus Touch installation manual
Dimensioned Drawings
Zeus Touch 7
15
229.5 mm (9.03") 260 mm (10.23")
161 mm (6.33")
168.5 mm (6.63")
166 mm (6.53")
140.5 mm (5.53")
234.5 mm (9.23")
212.5 mm (8.37")
SUN COVER
26.5 mm (1.04")
69.5 mm (2.73")
12 mm (0.47") 2.3 mm (0.09")
120 mm (4.72")
67 mm (2.63")
123 mm (8.77")
37 mm (1.45") 88 mm (3.46")
44.5 mm (1.75")
