3/3/2006

167-088Q-RUS

9

Pre-Assembly

Refer to Figure 3

3.

Unbolt and remove auger from rack.

Refer to Figure 4

4.

Unbolt and remove outer support arm
weldment and rear transport support from
ADC2220 frame in rack.

23430

Figure 3

Detach Auger

23437

Figure 4

Remove Support Weldments

23436

Refer to Figure 5

5.

Detach rockshaft from rack by removing u-
bolts.

Figure 5

Remove U-bolts
