Great Plains YP Fertilizer System - Manual (Page 33)

Great Plains Mfg., Inc.
Installation Instructions 33
02/29/2008 407-197M
2 803-053C NUT HEX SLOTTED 3/4-16
2 803-147C NUT HEX NYLOCK 1/2-13
2 804-013C WASHER LOCK SPRING 3/8 PLT
12 804-015C WASHER LOCK SPRING 1/2 PLT
1 804-017C WASHER FLAT 1/2 USS PLT
2 804-061C WASHER MACH 1.50 X 1.00 X 18GA
1 804-093C WASHER FLAT 3/4 HARD ASTMF436
6 804-113C WASHER FLAT 1/2 USS HARD PLT
3 804-157C WASHER SPRING LOCK M8 PLT
2 805-064C PIN COTTER 7/64 X 1 LONG
2 805-104C PIN COTTER 3/16 X 1 1/2 PLT
1 805-127C PIN CLEVIS 1/2 X 1 3/4
1 805-180C PIN ROLL 1/4 X 1 1/2 LG PLT
1 805-234C PIN CLEVIS 1/2 X 4 PLATED
4 805-240C PIN LINCH 3/16 X 1 9/16 LONG
2 808-147C SPKT 40C15 X 7/8 HEX BORE
1 808-149C SPKT 40C19 X 7/8 HEX BORE
1 808-156C SPKT 40C30 X 7/8 HEX BORE
1 808-219C SPKT 40C12 X 7/8 HEX BORE
1 808-249C SPKT 40C18 X 7/8 HEX BORE
1 808-251C SPKT 40C36 X 7/8 HEX BORE
1 808-276C SPKT 40C20 X 7/8 HEX BORE
1 808-338C SPKT 40C16 X 7/8 HEX BORE
1 817-358C KNOB 3/8-16 MALE THD 2 3/8OD
4 817-406C IDLER 1 PC 2.38X1.01X1.062
1 848-095C DECAL FERT DRIVE
1 407-171D FERT VALVE MNT
3 802-034C HHCS 1/2-13X1 1/4 GR5
3 803-020C NUT HEX 1/2-13 PLT
4 803-027C NUT HEX 3/4-10 PLT
3 804-015C WASHER LOCK SPRING 1/2 PLT
6 804-016C WASHER FLAT 1/2 SAE PLT
4 804-023C WASHER LOCK SPRING 3/4 PLT
4 804-025C WASHER FLAT 3/4 SAE PLT
2 806-102C U-BOLT 3/4-10 CORNER 7 SQ
1 829-013C VALVE 1 1/2FNPT BALL POLYPROP
1 830-045C AD 1 1/2MNPT POLYPROP
1 830-052C EL 1 1/2MNPT X 1 1/2FNPT POLYP
2 830-127C EL 1MNPT X 1HB POLYPROP
Callout Quantity Part Number
Part Description
(407-134A YP1225 & Y1625 FERT PUMP ONLY)
