Great Plains YP Fertilizer System - Manual (Page 29)

Great Plains Mfg., Inc.
Installation Instructions 29
02/29/2008 407-197M
8 800-125C CLAMP WRM DRV#28 SS(1.31-2.25)
2 802-034C HHCS 1/2-13X1 1/4 GR5
4 802-047C HHCS 1/2-13X6 GR5
16 802-258C HHCS 1/2-13X1 GR5
4 803-020C NUT HEX 1/2-13 PLT
4 803-147C NUT HEX NYLOCK 1/2-13
4 804-015C WASHER LOCK SPRING 1/2 PLT
4 804-016C WASHER FLAT 1/2 SAE PLT
1 805-010C PIN HAIR COTTER .094
2 829-013C VALVE 1 1/2FNPT BALL POLYPROP
1 829-048C VALVE - 1 1/2FNPT X 2FCL POLYP
4 830-021C PL 3/4MNPT POLYPROP
2 830-024C PL 1 1/2MNPT POLYPROP
4 830-031C TEE 1 1/2FNPT POLYPROP
5 830-045C AD 1 1/2MNPT POLYPROP
2 830-052C EL 1 1/2MNPT X 1 1/2FNPT POLYP
6 830-094C AD 1 1/2MNPT X 1 1/2HB POLYP
2 830-123C EL 3/4MNPT X 3/4HB POLYPROP
1 830-186C PL 2MCL POLY-GLASS
1 830-254C AD 1 1/2MNPT X 1HB POLYPROP
4 830-295C SP 3/4FNPT DBL THD BH PO BANJO
2 830-380C EL 3/4MNPT X 3/4FNPT SS
2 830-381C AD 3/4MNPT X 3/4HB SS
2 838-228C DECAL GREAT PLAINS ON LOGO SML
2 838-823C DECAL YP FERTILIZER LEVEL
1 can 890-310C RECTORSEAL 21 BLK THD SEALANT
2 890-522C MUFFLER CLAMP 2.50 SIZE
14 ft 990-078R HOSE 3/4ID X 1/8 WL CLEAR PVC
25 ft 990-082R HOSE 1 ID 200PSI EPDM
11 ft 990-181R HOSE 1 1/2 ID 150PSI EPDM
Callout Quantity Part Number
Part Description
(407-122A YP FERTILIZER TANK KIT)
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
