Great Plains Manufacturing, Inc. Appendix A - Reference Information 89
Appendix A - Reference Information
Specifications and Capacities
Tire Inflation Chart
3S-4010HD 3S-4010HDF
-4810 -6475 -4810 -6475
Operating Width 40 ft (12.2m) 40 ft (12.2m)
Swath 480in (1.219m) 484in (1.229m) 480in (1.219m) 484in (1.229m)
Number of Rows 48 64 48 64
Nominal Row Spacing 10in (25.4cm) 7.5in (19.1cm) 10in (25.4cm) 7.5in (19.1cm)
Swath-Averaged Row Spacing 10in (25.4cm) 7.56in (19.2cm) 10in (25.4cm) 7.56in (19.2cm)
Tractor Requirements
a
a. Minimum: power requirements vary with tractor size, soil type, terrain and tillage practices
325 hp (242 kW)
Weight
b
b. Typical weight; includes markers, frame-mounted coulters, small seeds option, but no material load or extra weights.
See “Transport” on page 23 for additional data.
37440 lbs
(16982 kg)
40400 lbs
(18325 kg)
37910 lbs
(17196 kg)
40870 lbs
(18538 kg)
Maximum Additional Weight 3 fully populated weight bracket sets: 3121 lbs (1416kg)
Capacities: Main Seed Box
Fertilizer (standard divider)
Fertilizer (offset divider kit)
Small Seeds
129.6 bu (4567 liters)
-
-
9.6 bu (338 liters)
71.3 or 129.6 bu (2512 or 4567 liters)
0 or 51.8bu (0 or 1827 liters)
41.5 or 58.3 bu (1461 or 2055 liters)
9.6 bu (338 liters)
Hydraulic Circuits
3 circuits required, open or closed center
4 circuits required with Markers
Hitch strap or clevis hitch
Transport Width 14ft 11.5in (4.56m)
Transport Heights
without Markers: 8ft 10in (2.69m)
with Markers: 13ft 8in (4.17m)
Operating Height
without Markers: 6ft 10in (2.08m)
with Markers: 11ft 8in (3.56m)
Length 45ft 0in (13.72m)
Wing Flexibility 12 degrees down, 12 degrees up
Tire Size 18-22.5 (445/65 D22.5) NHS 16-Ply
Tire Inflation Chart Tire Warranty Information
Tire Size Inflation All tires are warranted by the original manufacturer of
the tire. Tire warranty information is found online at the
manufacturer’s web sites listed below. For assistance
or information, contact your nearest Authorized Farm
Tire Retailer.
ManufacturerWeb site
Firestone
www.firestoneag.com
Gleason www.gleasonwheel.com
Titan www.titan-intl.com
118-22.5 (445/65 D22.5) NHS 16-Ply
85 psi
586 kPa
