Profile series v.g1.5 exit device, Item part no. description req’d – SARGENT Profile Series v.G1.5 Exit Devices User Manual
Page 5

3
A7856B • 800-810-WIRE (9473) • www.sargentlock.com
Profile Series v.G1.5 Exit Device
0
5
/0
4
/0
9
A
7
8
5
6
:B
C
o
p
yr
ig
h
t
©
2
0
0
9
,S
a
rg
e
n
t
M
a
n
u
fa
c
tu
ri
n
g
C
o
m
p
a
n
y,
a
n
A
S
S
A
A
B
LO
Y
G
ro
u
p
c
o
m
p
a
n
y.
A
ll
ri
g
h
ts
re
se
rv
e
d
.
R
e
p
ro
d
u
c
ti
o
n
in
w
h
o
le
o
r
in
p
a
rt
w
it
h
o
u
t
th
e
e
xp
re
ss
w
ri
tt
e
n
p
e
rm
is
si
o
n
o
f
S
A
R
G
EN
T
M
a
n
u
fa
c
tu
ri
n
g
is
p
ro
h
ib
it
e
d
.
ITEM
PART No.
DESCRIPTION
REQ’D
1
52-2839
Outside Escutcheon (Prox Only) Assembly (G1-PA, G1-TA)
1
52-2474
Outside Escutcheon (Keypad Only) Assembly (LK)
1
52-2838
Outside Escutcheon (Keypad/Prox) Assembly (G1-LU, G1-PK, G1-TU, G1-TP)
1
52-2704
Key Pad and Proximity Assembly (G1-LU, G1-PK, G1-TU, G1-TP)
1
52-2432
Keypad/Proximity Bezel Assembly w/ Harness (LK)
1
52-2706
Proximity Only Assembly (G1-PA, G1-TA)
1
68-1397
Outside Escutcheon Housing Only
1
52-0176
Outside Escutcheon End Cap
1
2
52-2460
Inside Escutcheon Assembly with 100 User Controller (LK)
1
2
52-2833
Inside Escutcheon Assembly with 2000 User Controller (G1-LU)
1
2
52-2834
Inside Escutcheon Assembly with Prox/Key Pad Controller (G1-PA, G1-PK)
1
52-2836
Inside Escutcheon Assembly (Keypad Only)
with RF Technology Controller (G1-TU)
52-2835
Inside Escutcheon Assembly (Keypad/Prox or Prox Only)
with RF Technology Controller (G1-TA, G1-TP)
68-1396
Inside Escutcheon Housing Only
1
52-0175
Inside Escutcheon End Cap Only
1
52-2441
100 User Controller Assembly (LK)
1
52-2783
2000 User Controller Assembly (G1-LU)
1
52-2784
2000 User Controller Assembly (G1-PA, G1-PK)
1
52-2786
2000 User (Keypad/Prox or Prox Only) Controller Assembly w/ RF Technology (G1-TA, G1-TP)
52-2785
2000 User (Keypad Only) Controller Assembly w/ RF Technology (G1-TU)
3
52-0170
Battery Cover
1
52-2309
Battery Cover – RF Technology (G1-TU,G1-TP, G1-TA)
4
01-1212
Security Screw
1
5
01-0297
Security Tool
1
6
52-0033
Fire Stop Plate
1
7
01-1500
Fire Stop Screws #8 x 1/2” Type “AB” Phillips Pan Head Self Tap
2
01-0803
Battery Alkaline (“AA” Cell)
6
9
52-0253
Battery Keeper
1
52-0344
Battery Keeper – RF Technology (G1-TU, G1-TP, G1-TA)
10
52-2425
Screw Pack (Includes item numbers 5, 6, 7, 15)
1
11
Consult Factory
Motorized ET Lever Trim
1
12
Consult Factory
Motor and Harness Assembly
1
13
01-4451
ET Through-bolts
2
14
13-0074
Cylinder Retaining Screws
2
15
77-0685
Escutcheon Through-bolts
2
16
68-4261
Center Case Assembly LHRB & RHRB (Std.)
1
68-4263
Center Case Assembly LHRB (12-) & RHRB (12-)
1
17
68-0406
Chassis Cover
1
18
97-0052
Chassis Cover Screws
4
