SARGENT Profile Series v.G1.5 Exit Devices - Manual (Page 15)

13
A7856B • 800-810-WIRE (9473) • www.sargentlock.com
Profile Series v.G1.5 Exit Device
0
5
/0
4
/0
9
A
7
8
5
6
:B
C
o
p
yr
ig
h
t
©
2
0
0
9
, S
a
rg
e
n
t
M
a
n
u
fa
c
tu
ri
n
g
C
o
m
p
a
n
y,
a
n
A
S
S
A
A
B
LO
Y
G
ro
u
p
c
o
m
p
a
n
y.
A
ll
r
ig
h
ts
r
e
se
rv
e
d
.
R
e
p
ro
d
u
c ti
o
n
in
w
h
o
le
o
r
in
p
a rt
w
it
h
o
u
t
th
e
e
xp
re
ss
w
ri
tt
e
n
p
e
rm
is
si
o
n
o
f
S
A
R
G
EN
T
M
a
n
u
fa
c tu
ri
n
g
is
p
ro
h
ib
it
e
d
.
ITEM PART No. DESCRIPTION REQ’D
1 52-2839 Outside Escutcheon (Prox Only) Assembly (G1-PA, G1-TA) 1
1 52-2838 Outside Escutcheon (Keypad/Prox) Assembly (LK, G1-LU, G1-PK, G1-TU, G1-TP) 1
52-2432 Keypad/Proximity Bezel Assembly w/ Harness (LK) 1
52-2704 Key Pad and Proximity Assembly (LK, G1-LU, G1-PK) 1
52-2706 Proximity Assembly (G1-PA, G1-TA) 1
68-1397 Outside Escutcheon Housing Only 1
52-0176 Outside Escutcheon End Cap Only 1
2 52-2460 Inside Escutcheon Assembly with 100 User Controller (LK) 1
2 52-2833 Inside Escutcheon Assembly with 2000 User Controller (G1-LU) 1
2 52-2834 Inside Escutcheon Assembly with Prox/Key Pad Controller (G1-PA, G1-PK) 1
52-2836 Inside Escutcheon Assembly (Keypad Only)
with RF Technology Controller (G1-TU)
52-2835 Inside Escutcheon Assembly (Keypad/Prox or Prox Only)
with RF Technology Controller (G1-TA, G1-TP)
68-1396 Inside Escutcheon Housing Only 1
52-0175 Inside Escutcheon End Cap Only 1
52-2441 Enclosure (LK) Assembly 1
52-2783 Enclosure (G1-LU) Assembly 1
52-2784 Key Pad/Proximity Only Controller (G1-PA, G1-PK) Assembly 1
52-2786 2000 User (Keypad/Prox or Prox Only) Controller Assembly (G1-TA, G1-TP)
52-2785 2000 User (Keypad Only) Controller Assembly (G1-TU)
01-0803 Battery Alkaline (“AA” Cell) 6
3 52-0170 Battery Cover 1
52-2509 Battery Cover – RF Technology (G1-TU,G1-TP, G1-TA)
4 01-1212 Security Screw 1
5 01-0297 Security Tool 1
6 52-0033 Fire Stop Plate 1
7 01-1500 Fire Stop Screws #8 x 1/2” Type “AB” Phillips Pan Head Self Tap 2
9 52-0253 Battery Keeper 1
52-0344 Battery Keeper – RF Technology (G1-TU, G1-TP, G1-TA)
10 52-2425 Screw Pack (Includes item numbers 5, 6, 7, 15) 1
11 Consult Factory Motorized ET Lever Trim 1
12 Consult Factory Motor and Harness Assembly 1
13 01-4451 ET Through-bolts 2
15 77-0685 Escutcheon Through-bolts 2
16 68-2172 Center Case Assembly LHRB (Standard and 12-) 1
16 68-2173 Center Case Assembly RHRB (Standard and 12-) 1
17 99-2401 Mortise Lock LHRB 1
17 99-2402 Mortise Lock RHRB 1
18 68-0407 Chassis Cover 1
19 97-0052 Chassis Cover Screws 4
