4.04 Weld Parameters for ArcMaster 200 ACDC
Weld Mode
Weld
Parameter
Parameter
Range
Factory
Setting
Incremental
Unit
STICK
HF
TIG
LIFT
TIG
PRE-FLOW
0.0 to 1.0 sec
0 sec
0.1 sec
No
Yes
Yes
HOT START
0 to 70A
20A
1A
Yes
Yes
No
INITIAL CUR.
5 to 200A
30A
1A
No
Yes
Yes
UP SLOPE
0 to 15 sec
1 sec
0.1 sec
No
Yes
Yes
PULSE PEAK CUR.
5 to 200A
120A
1A
No
Yes
Yes
PULSE BASE CUR.
5 to 200A
5A
1A
No
Yes
Yes
WELD CUR.
(TIG)
5 to 200A
80A
1A
No
Yes
Yes
WELD CUR.
(STICK)
5 to 160A
80A
1A
Yes
No
No
SPOT TIME
0.5 to 5.0 sec
2 sec
0.1 sec
No
Yes
Yes
PULSE WIDTH
15 to 80%
50%
1%
No
Yes
Yes
PULSE FREQ.
0.5 to 500Hz
100.0Hz
See
Table 6
No
Yes
Yes
AC FREQUENCY
15 to 150Hz
50Hz
1Hz
Yes
Yes
Yes
WAVE BALANCE
10 to 65%
50%
1%
Yes
Yes
Yes
DOWN SLOPE
0 to 25 sec
3 sec
0.1 sec
No
Yes
Yes
CRATER CUR.
5 to 200A
30A
1A
No
Yes
Yes
POST-FLOW
0.0 to 60 sec
10 sec
0.1 sec
No
Yes
Yes
Table 5 – Weld Parameters for ArcMaster 200 ACDC
PULSE FREQ.
Range
Incremental Unit
z
H
1
.
0
z
H
0
2
o
t
5
.
0
z
H
1
z
H
0
0
1
o
t
0
2
z
H
5
z
H
0
0
5
o
t
0
0
1
Table 6 –
PULSE FREQ.
Range and Incremental Units
