17
3.04 Specifications
Parameter 200 ACDC
Rated Output
Amperes
Volts
Duty Cycle
200
18
20%
Duty Cycle TIG 200A / 17.4V @ 20%
160A / 16V @ 40%
130A / 15V @ 60%
100A / 14V @ 100%
STICK 160A / 26V @ 40%
130A / 25V @ 60%
100A / 25V @ 100%
Output Current TIG 5 – 200 (DC)
5 – 200 (AC) @ 60Hz, 50% Cleaning
Range STICK 5 – 160 (DC)
5 – 160 (AC)
Open Circuit Voltage 65V
Dimensions
Width
Height
Length
7.08” (180mm)
14.7” (360mm)
16.54” (420mm)
Weight 41.8 lb. 19 kg
Output @ Rated Load
Rated Input Voltage
Output Amperes
Output Volts
Duty Cycle
KVA
KW Three-phase
208-230/460V
160A
26V
40%
7.5
5.2 Single-phase
208-230V
160A
26V
40%
8.7
5.2
Output @ No Load
KVA
KW
0.5 0.5
0.13 0.13
Input Volts Three Phase
208V
230V
460V
Input Volts Single Phase
208V
230V
Amperage Draw @ Rated Load
21
19
10
42
38
No Load Amps
1.4
1.3
0.6
2.2
1.6
Thermal Arc continuously strives to produce the best product possible and therefore reserves the right to change, improve or revise the
specifications or design of this or any product without prior notice. Such updates or changes do not entitle the buyer of equipment previously
sold or shipped to the corresponding changes, updates, improvements or replacement of such items. The values specified in the table above
are optimal values, your values may differ. Individual equipment may differ from the above specifications due to in part, but not exclusively, to
any one or more of the following; variations or changes in manufactured components, installation location and conditions and local power grid
supply conditions.
