3.03.02 Input Power

Each unit incorporates an INRUSH circuit and input voltage sensing circuit. When the MAIN CIRCUIT
SWITCH is turned on, the inrush circuit provides a pre-charging of the input capacitors. SCR’s in the Power
Control Assembly (PCA) will turn on after the input capacitors have charged to full operating voltage (after
approximately 5 seconds).

Note 5

Note the available input power. Damage to the PCA could occur if 575VAC or higher is applied.

The following 208-230/460V Primary Current recommendations are required to obtain the maximum
welding current and duty cycle from this welding equipment:

Current & Duty Cycle

Model

Primary Supply

Lead Size (Factory

Fitted)

Minimum Primary

Current Circuit Size

(Vin/Amps)

TIG STICK

208/18 -
230/16 -

460/8

200 @ 20%

208/21 -
230/19 -

Phase

460/10 -

160 @ 40%

208/36 -
230/33

200 @ 20%

208/42 -

ArcMaster
200 ACDC

8/4 AWG minimum

Phase

230/38 -

160 @ 40%

Table 2 – 208-230/460V Primary Current Circuit sizes to achieve maximum current

The ARCMASTER 200 ACDC is designed for use with a generator as an input power source. Contact an
accredited Thermal Arc service agent for the proper sizing and set-up recommendations of a generator power
source system. As a general rule, depending on the type of generator used, the generator capacity should be
twice the maximum rating of the welder.
