Manual 0-2557 37 PARTS LISTS
Item # Qty Description Catalog #
23 1 Handwheel (Torch Holder) 9-4514
24 1 Low Profile Torch Holder (1 3/8 Dia) w/o Hardware 9-4515
25 1 Calibrated Torch Holder Bushing (Includes item #26) 9-4366
26 1 #10-24 x 3/8 Hex Socket Set Screw, Cup Point See Note
27 1 5/32 Dia x 5/8 Lg Slotted Spring Pin See Note
28 1 3/8-24 x 3/8 Soc Hd Set Screw, Cup Point See Note
29 2 1/4-20 x 5/8 Hex Socket Head Screw See Note
NOTE: Item can be purchased locally.
18
23
29
19
24
25
21
26
22
7
17
14
15
9
16
11
10
17
8
1
4
2
3
5
A-00647
6
13
12
27
28
20
29
