APPENDIX A-16 Manual 0-4640
A
APPENDIX 16: AUTOMATION INTERFACE PC BOARD
WIRING CONNECTIONS TO OEM CNC HARNESS
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Art # A-04151
Torch Switch (P
ositiv
e)
to CPC Hous
ing, Pin 4
To
rch Switch (Ne
gativ
e) to
CPC Housing,
Pin 3
OK to
Mo
ve to
CPC Housing,
Pin 14
OK to Mo
ve to CPC Housing, P
in 12
Divided
Outpu
t (P
ositiv
e) to CPC Housing, P
in 6
Divided
Outpu
t (Negativ
e) to CPC Housing,
Pin 5
Logic Common
to CPC Hous
ing, Pin 8
Open Open Open Open Open Open Open
Open Arc V
olts
(P
ositiv
e) to CPC Housing,
Pin 9
Arc
Volts (Negativ
e) to CPC Housing, P
in 7
Open Open Open
To Main PC Board
Terminal J27-3
To Main PC Board
Terminal J27-1
To Main PC Board
Terminal J27-2
Installed only with
Optional Remote Current Control
Terminal Block J4
Automation Interface PC Board
