Tweco 51 with SL100SV CutMaster - Manual (Page 124)

PARTS LISTS 6-10 Manual 0-4640
6
6.09 Right Side Internal Replacement Parts
Item # Qty Description Ref Catalog #
1 1 Assembly, Pressure Switch/Solenoid SOL1, PS1 9-8329
2 1 Assembly, Pilot PCB 9-7985
3 Fan, 220V, 115 CFM M1 9-7687
4 1 Assembly, Main Transformer T5 9-8544
5 1 Assembly, Output Inductor L1 9-8560
6 1 Automation Interface PC Board 9-4894
7 1 Automation Interface Wire Harness 9-4895
8 1 Transformer (only in power supplies connected to SL100SV Torch 9-9449
[with solenoid on mounting tube])
Hardware:
A 5 10-32 x 1/2 pph screw See Note
B 1 #10 External star washer See Note
C 1 1/4-20 nut, brass See Note
D 3 10-32 Kepnut w/ star washer See Note
E 4 6-32 x 3/8" pph screw See Note
F 2 6-32 x 3-1/2" pph screw See Note
G 1 1/4" External star washer See Note
H 1 1/4-20 X 1" hex bolt, brass See Note
NOTE
May be purchased locally.
