PARTS LISTS 6-6 Manual 0-4640
6
6.07 Left Side Internal Replacement Parts
Item # Qty Description Ref Catalog #
1 Fuse F1
1 1/2A, 250V (For 208/230-Volt units) 9-8110
1 1/2A, 600V (For 400-Volt and 460-Volt units) 9-8583
Main Input Contactor W1
2A 1 For 208/230-Volt Units 9-8522
2B 1 For 400-Volt and 460-Volt Units 9-8554
3 PCB Kit, Input Diode 9-7088
1 Input Diode
1 Thermal Pad
2 External star washer
2 Screw, 8-32 x 1/2", PPH
4 1 PCB Assembly, Logic 9-7996
5 1 PCB Kit, IGBT Circuit 9-8540
1 Round Thermal pad
6 1 PCB Kit, Output Diode 9-8539
1 Round Thermal pad
7 PCB Kit, Main Power
1 For 208/230-Volt Units 9-7993
1 For 400-Volt Units 9-7994
1 For 460-Volt Units 9-7995
8 1 EMI Filter Assembly (CE Units only) 9-8561
Hardware:
A 4 Hex nut See Note
B 2 Screw, 8-32 x 3/4, PPH, with external star washer See Note
C 3 Washer, 0.125 ID, zinc See Note
D 1 Screw, 8-32 x 1", PPH, with external star washer See Note
E 10 Screw, 6-32 x 3/8, PPH, with external star washer See Note
NOTE
May be purchased locally.
