Adjusting the Room Set Temperature (No Schedule) Section C1
If no schedule is being used, the heating and cooling temperature can be permanently adjusted from the View menu
when viewing either the “Room” or “Room Set” items.
Adjusting the Room Set Temperature (Schedule) Section C2
When using a schedule, the heating and cooling temperature
for each schedule event can be permanently changed from
the Adjust menu. There will be one “Set Heat” and one “Set
Cool” item in the Adjust menu for each scheduled event.
In a two event schedule, the events are:
Occ (Occupied) • UnOcc (UnOccupied) •
In a four event schedule, the events are:
Wake
UnOcc •
• Occ
Sleep •
•
When scenes are used, an additional ‘Away’ event is
available.
If a schedule is not in use, only the Set Heat Occ and Set
Cool Occ settings are available.
Wait 10
seconds
Current schedule
status indicates a
schedule is in use
Press Up or Down
Button to adjust
the heating “Wake”
temperature.
Press Up or Down
Button to adjust the
heating “UnOcc”
temperature
Press Up or Down
Button to adjust the
heating temperature.
Press Up or Down
Button to adjust the
cooling temperature.
OR
