tekmar 544 Thermostat Installation - Manual (Page 8)

© 2008 D 544 - 07/08 8 of 36
Item Field Range Access Description
NONE, 1
Default = 1
INST
ADV
COOL STAGES SECTION G
Select the number of cooling stages. Select None if
cooling is not used.
0:30 to 6:00 min
Default = 2:00
ADV
MINIMUM COOL RUN TIME SECTION G
Select the minimum running time for the cooling
equipment.
Note: This item is only available when the Cool Stage
is set to 1.
0:30 to 10:00 min
Default = 5:00
ADV
MINIMUM COOL OFF TIME SECTION G
Select the minimum off time for the cooling
equipment.
Note: This item is only available when the Cool Stage
is set to 1.
AUTO, 2 to 12
Default = AUTO
ADV
COOL CYCLES PER HOUR SECTION D
Select the number of cooling cycles per hour.
Note: This item is only available when the Cool Stage
is set to 1.
10 to 180 min
Default = 30
ADV
INTERLOCK SECTION G
Select how long heating must be off before cooling
starts.
Note: This item is only available when the Cool Stage
is set to 1.
NONE, 1, 2
Default = 1
INST
ADV
FAN MODE SECTION H
Select the operation of the Fan 1 output.
OFF, ON
Default = OFF
ADV
FAN VENTILATION SECTION H
Select whether the Fan output is required for
ventilation.
Note: This item is only available when the Fan Mode
is set to None.
OFF, 1 to 60 min
Default = OFF
ADV
VENTILATION PRE-VENT SECTION H
Select how long the ventilation operates continuously
prior to the Wake or Occupied events.
Note: This item is only available when the Fan Mode
is set to None and F1 Vent is set to On.
Adjust Menu (3 of 4)
Continued on next page.
