© 2008 D 544 - 07/08 6 of 36
Item Field Range Access Description
OFF, HEAT,
AUTO, COOL
Default = AUTO
USER
INST
ADV
MODE OF OPERATION SECTION B
Mode of operation of the thermostat or cool group.
40 to 95°F
(4.5 to 35.0°C)
LTD
USER
INST
ADV
SET HEAT SECTION C
Selected air heating temperature for each event.
Note: At the Limited Access Level, you can only
adjust the temperature +/-3°F (1.5°C) from the last
setting.
Away is only available when Scenes are turned on.
Wake Default = 70°F (21.0°C)
UnOccupied Default = 62°F (16.5°C)
Occupied Default = 70°F (21.0°C)
Sleep Default = 62°F (16.5°C)
Away Default = 62°F (16.5°C)
50 to 100°F
(10.0 to 38.0°C)
LTD
USER
INST
ADV
SET COOL SECTION C
Select the cooling room temperature for each event.
Note: At the Limited Access Level, you can only
adjust the temperature +/-3°F (1.5°C) from the last
setting.
Away is only available when Scenes are turned on. Wake Default = 78°F (25.5°C)
UnOccupied Default = 85°F (29.5°C)
Occupied Default = 78°F (21.0°C)
Sleep Default = 85°F (29.5°C)
Away Default = 85°F (29.5°C)
OFF, 40 to 122°F
(OFF, 4.5 to 50.0°C)
LTD
USER
INST
ADV
FLOOR MINIMUM SECTION F
Select the minimum floor temperature for each
event.
Note: This item is only available when Sensor 1 or 2
is set to Floor. At the Limited Access Level, you can
only adjust the temperature +/-3°F (1.5°C) from the
last setting.
Wake Default = 70°F (21.0°C)
UnOccupied Default = OFF
Occupied Default = 70°F (21.0°C)
Sleep Default = OFF
Adjust Menu (1 of 4)
The Adjust Menu items are the programmable settings
used to operate the mechanical equipment.
Continued on next page.
