Powers 593 Series Flowrite II Heavy Duty Bronze Globe Control Valves User Manual
Page 3
TI147-POS Page 3
PARTS AND ACCESSORIES LIST
CLOSED
OPEN
N.C.
46 sq.in.
OPEN
CLOSED
N.O.
46 sq.in.
Air Connections
on top
Note: Install take-off
plate with flange up
Note: Pin sits on top
of take-off plate
Air Connections
on bottom
Note: Install take-off plate
with flange down
Note: Pin sits underneath
take-off plate
Figure 2 - 46 Actuator N.O. Mounting
Figure 1 - 46 Actuator N.C. Mounting
