Powers 450-e420 HydroPanel II Shower System - Extensions - Manual (Page 4)

TI 450SH v3 Page 4
7.096"
2.448"
1-1/8"
1/4 W X 3/4 L (ONE EACH SIDE)
3/8"
Overlays
A
B Product No.
13” 6.5” 450 4044
16” 8” 450-4045
18” 9” 450 4046
23” 11.5” 450 4047
28” 14” 450-4048
10-32 UNF-2B THD.
1-1/8"
1/2"
1"
1"
1-1/2"
1/4" DIA.
1/2"
.375"
7.080"
6.960"
5/8"
2.370"
Accessories
Item
Product No.
Bracket 450 334
Accessories
Item
Product No.
End Cap 450 4011
Qty Description Size (Metric) Order #
Horizontal Adapter Kit 16” 405mm 450 4040
Horizontal Adapter Kit 24” 610mm 450 4041
Horizontal Adapter Kit 48” 1220mm 450 4042
Overlay Shroud Kit 8” 205mm 450 4043
Overlay Shroud Kit 13” 330mm 450 4044
Overlay Shroud Kit 16” 405mm 450 4045
Overlay Shroud Kit 18” 455mm 450 4046
Overlay Shroud Kit 23” 585mm 450 4047
Overlay Shroud Kit 28” 710mm 450 4048
Corner Adapter Kit 10” 255mm 450 4049
Qty Description Size (Metric) Order #
Extension Shroud Kit 6” 150mm 450 4050
Extension Shroud Kit 24” 610mm 450 4051
End Cap Kit 450 4011
Bracket Kit 450 334
Each Hydropanel II Modular Shrouding Corner Adapter, 13”, 16”, 18”, 23”, or 28” Overlay, or
Extension Kit comes complete with stainless steel panel, and (2) mounting brackets with (2) screws.
Each Horizontal Adapter or 8” Overlay Kit comes complete with stainless steel panel and (4) mounting
brackets with (4) screws.
The 16” Horizontal Adapter Kit also includes an End Cap kit. The End Cap Kit comes complete with (1)
chrome plated end cap and (3) mounting screws.
