LS-800
Specifications
Optical Fiber Camera Adaptor LS-800
Features, design and specifications are subject to change without notice.
Output
2
1 (BNC x1) : 1Vp-p, 75Ω, Analog composite or HD-Y
1 (BNC x1) : 1Vp-p, 75Ω, Analog composite or HD-Y, Telepromoter input
HD-Y/VIDEO composite
Prompter/Ref.video
Input
DC
1 (XLR 4-pin(male) x1) : 12 V
3G/HD/SD-SDI
Intercom
Intercom headset
1 (XLR 4-pin(male) x1)
Remote
Remote
8-pin or 10-pin ※
Optical fiber connection
Plug
LEMO P/N: FXW.3K.93C.TLM
Maximum distance
approx. 1.25 miles (2 km ) with DC power supplied to LS-700 via optical fiber cable
General
Weight
approx. 7.28 lbs. (approx. 3.3 kg)
Dimensions (WxHxD)
8.46 x 4.53 x 11.9 inches (215 x 115 x 302 mm)
/ DC operation Maximum: approx. 28 W
Power requirement
+32 F to 104 F (0 ℃ to 40 ℃)
-4 F to 140 F (-20 ℃ to 60 ℃)
Operating temperature
Storage temperature
3G/HD/SD-SDI (Return)
Audio (CA audio)
2 (XLR 3-pin(male) x2) : LINE=+4 dB, MIC= -60 dB
2
HD-Y/VIDEO Composite
2 (BNC x2) : 1Vp-p, 75Ω, Analog composite or HD-Y
Audio (Program audio)
Tally
1 (HD D-sub 15-pin(female) x1)
2 (XLR 3-pin(female) x2) : LINE=+4 dB, MIC= -60 dB
2W line
4W line
2, Producer line (XLR 3-pin(female/male) x1/1)
1 (HD D-sub 15-pin(female) x1)
AC operation Maximum: approx. 128 W
Time Code
Remote Video
Monitor
1 (BNC x1) (Composite)
1 (BNC x1)
1 (Stereo headphone jack φ 6.3mm x1)
Time Code
1 (BNC x1)
1 (BNC x1)
Reference
Tally
1 (HD D-sub 15-pin(female) x1)
2, Engineer line (XLR 3-pin(female/male) x1/1)
Power consumption
/ DC : 12 V(12-16V)
AC : 100/200 V(85-240V) 60Hz/50Hz
※ : 8-pin for SONY RM-B750 or RM-B150 and 10-pin for Panasonic AG-EC4G or AJ-RC10G.
(HD/SDI OUT 1: BNC x3) 3G/HD/SD, Audio,TC embedded
(HD/SDI OUT 2: BNC x4) 3G/HD/SD, Audio,TC embedded
(RET HD/SDI IN 1: BNC x1) 3G/HD/SD, Audio,TC embedded
(RET HD/SDI IN 2: BNC x1) 3G/HD/SD, Audio,TC embedded
