46

CA audio signal monitoring and setting

2

Set the CA AUDIO OUT (1/2), MIC/LINE, select switch to the appropriate position
according to the rated level of the equipment connected to the CA AUDIO OUT 1/2 connectors.

Check the input level by AUDIO IN 1/2 level meters.

Set the CA/PGM select switch to the CA position.

Adjust the audio level of the headphone by the MONI. volume.

LINE LINE

MIC

MIC

CA AUDIO

ST

CA

PGM

MONI

OUT

MONI.VOL

MONI

OVER

OVER

CA AUDIO

LANC

TALLY

OPT

HD/SDI OUT 1

IN

OUT

HD-Y/VIDEO

OUT

HD/SDI IN1

HD/SDI

RET

1

2

1

2

AUDIO IN

CA

AUDIO OUT

PGM

Connect a headphone to the MONI connector to monitor the CA audio signal
and input the audio signal to the AUDIO IN 1/2 connector of LS-700 or turn on the 1 kHz ON/OFF
switch of LS-700.

MONI
headphone
connector
(φ 6.3)

Select the audio monitor channel 1, 2, or 1/2stereo by the MONI select switch.

to
switcher,
audio mixer,
VTR,
etc.

(rear panel)

(front panel)

Adjustments and Settings for LS-800

HEADPHONE

CA audio signal

Optical Fiber Camera Adaptor LS-700/Optical Fiber Base Station LS-800

LS-700/LS-800

LS-800
