AR/GE/FE/U 80/80X Installation Manual
16 580­00519 rev. D
3.7 Cable Installation
3.7.1 Fiber Cabling
1. Install a duplex multi­mode fiber from the radio to the network termination equipment
(switch or router with 1000Base­X port). The cable should be looped around the inside of the
enclosure to provide strain­relief. Do not connect the fibers to the radio’s fiber ports at this
time.
The connectors on the radio end of the fiber require two LC connectors; the connectors on
the switch/router end should mate to the network equipment.
2. Connect fibers at the network equipment.
It is important not to connect the fibers to the radio until after
aligning the radio as the radio performs an automatic calibration
once the fiber is inserted into the radio and this calibration will
not operate properly if the radio is not properly aligned. If this
inadvertently occurs while the radio is powered on, unplug the
fibers and power cycle the radio.
3.7.2 Power Cabling
1. Select indoor location, with easy cable routing to the radio, for the AC power adaptor.
Normally it is convenient, but not required, to place the adaptor near the network termination
equipment.
2. Ensure the DC wire used is 14­gauge type and no longer than 125 meters; or 12­gauge and
no longer then 200 meters.
3. Connect the provided DC Connectors onto the 14­guage wire using a splicing/crimping tool.
For the use of 12­gauge wire it may be necessary to trim a few strands from the ends of
thicker stranded cables to more easily fit the crimp connectors.
4. Install the DC power cable and attach to the AC adaptor using the supplied crimp connectors.
Do not connect the power jack to the radio at this time.
The fiber and power cables are inserted through the straight
through fitting before the 3/4" flexible conduit is connected to the
fitting. Ensure that the cables do not get pinched when the conduit
is pushed onto the fitting. Both cables should be looped around the
inside of the enclosure to minimize tension on the cables when
connected to the radio and to maintain proper bend­radius of the
fiber cable. See Figure 3.7.2­1
