4 E-flite Deuces Wild Assembly Manual
Required Tools and Adhesives
Tools & Equipment
Felt-tipped pen Ball driver: 3/32-inch
Low-tack masking tape Mixing sticks
Paper towels Pin drill
Rubbing alcohol Mixing cups
Hobby knife (#11 blade) Pliers
Phillips screwdriver: #1, #2 Side cutters
Sandpaper Nut driver: 1/4-inch
Pencil Drill
Covering iron Flat screwdriver
Dental floss Scissors
Rotary tool w/high speed cutting bit
Drill bit: 1/16-inch (1.5mm), 5/64-inch (2mm),
3/32-inch (2.5mm), 3/16-inch (5mm)
Adhesives
Thin CA Medium CA
Threadlock 6-Minute Epoxy (HAN8000)
Canopy glue Silicone adhesive
Notes Regarding Servos and ESC
WARNING: Use of servos other than those we suggest may
overload the BEC of the recommended Electronic Speed Control
(ESC). Please use only the servos listed when utilizing the
recommended ESC’s BEC, or the use of a separate BEC (like the
UBEC) or receiver battery pack when using other servos.
Brushless Outrunner Setup, Power 25
EFLM4025A (2 req) Power 25 Brushless Outrunner Motor
870Kv
EFLA1060 (2 req) 60-Amp Pro Switch-Mode BEC
Brushless ESC
EFLB32003S (2 req) E-flite 3S 11.1V 3200mAh 20C Li-Po
APC12080E (1 req) 12x8 Electric Propeller
APC12080EP (1 req) 12x8 Electric Pusher Propeller
Brushless Outrunner Setup, Power 32
EFLM4032A (2 req) Power 32 Brushless Outrunner Motor,
770Kv
EFLA1060 (2 req) 60-Amp Pro Switch-Mode BEC
Brushless ESC
THP33004SXV (2 req) 4S 14.4V 3300mAh 25C Li-Po battery
APC13065E (1 req) 13x6.5 Electric Propeller
APC13065EP (1 req) 13x6.5 Electric Pusher Propeller
Optional Accessories
EFLA110 Power Meter
EFLC505 Intelligent 1- to 5-Cell Balancing Charger
EFL4562 Cockpit Kit, Deuces Wild ARF
EFL4565 Retracts, Deuces Wild ARF
DUB141 3/16-inch Wheel Collars (required for
retract installation)
Covering Colors
White HANU870
Flame Red HANU883
Black HANU874
