21 E-flite Deuces Wild Assembly Manual
Flap Servo Installation
Required Parts
Wing center section Servo w/hardware
Brass pushrod connector Nylon connector backplate
Flap linkage Nylon clevis (2)
Silicone clevis retainer (2) 3mm x 5mm machine screw
Nylon control horn (2)
Required Tools and Adhesives
Felt-tipped pen Pin drill
Thin CA Side cutter
Phillips screwdriver: #1 Pliers
Threadlock
Drill bit: 1/16-inch (1.5mm), 5/64-inch (2mm)
 1. Position the flap servo into the wing. Use a felt-tipped
pen to transfer the locations for the servo mounting
screws onto the wing.
 2. Use a pin drill and 1/16-inch (1.5mm) drill bit to drill
the holes to mount the flap servo.
 3. Apply 2–3 drops of thin CA into each of the four
holes. This will harden the surrounding wood to provide
a hard surface for the screws to bite into so they will be
more secure when installed.
