Dimensions
8.5 mm
(0.33")
88 mm
(3.5")
53 mm
(2.1")
20.5 mm
(0.80")
20.5 mm
(0.80")
30.5 mm
(1.20")
20.5 mm
(0.80")
M20 x 1.5
40 mm
(1.6")
max. 197 mm / min. 185 mm
(max. 7.8" / min. 7.3")
127 mm
(5.0")
10 mm
(0.4")
85.5 mm
(3.37")
8 mm
(0.3")
90 mm
(3.5")
72 mm
(2.8")
78 mm
(3.1")
48 mm
(1.9")
Ø 6.5 mm
x 4
(0.26")
Ø 5.4 mm
x 4
(0.21")
Figure 13. RP-RM83F-..LR..
RP-RM83F Heavy-Duty Rope Pull Emergency Stop Switches
