Specifications

Contact Rating

10A @ 24V ac, 10A @ 110V ac, 6A @ 230V ac; 6A @
24V dc
2.5 kV max. transient tolerance
NEMA A300 P300

Contact Material

Silver-nickel alloy

Maximum Switching Speed

30 operations per minute

Maximum Actuator Speed

1 m/second (39"/second)

Minimum Actuator Engagement Radius

In-line actuators: 150 mm (6 inches)
Flexible actuators: 50 mm (2 inches) in all directions

Actuator Extraction Force

High force models: 50 Newtons (11 lbf)
All other models: 10 Newtons (2.2 lbf)

Short Circuit Protection

6 amp Slow Blow, 10 amp Fast Blow. Recommended
external fusing or overload protection.

Wire Connections

Screw terminals with pressure plates accept the follow-
ing wire sizes –
For switches with one or two contacts: Stranded and
solid: 20 AWG (0.5 mm2) to 16 AWG (1.5 mm2) for
one wire; Stranded: 20 AWG (0.5 mm2) to 18 AWG
(1.0 mm2) for two wires
For switches with three contacts: Stranded and solid:
20 AWG (0.5 mm2) to 18 AWG (1.0 mm2) for one wire;
Stranded: 20 AWG (0.5 mm2) to 18 AWG (1.0 mm2)
for two wires

Cable Entry

SI-QS75 models: M16 x 1.5 threaded entrance
SI-QS90 models: M20 x 1.5 threaded entrance
Adapter supplied to convert to ½"-14 NPT threaded en-
trance.

European Rating

Utilization categories: AC15 and DC13 (IEC 60947-5-1)
Switches with 1 and 2 contact pairs: Ui = 500V ac; Ith =
10 A
Switches with 3 contact pairs: Ui = 400V ac; Ith = 5A

40-60 Hz

Ie/AC-15

Ie/DC-13

110

230

0.4

Mechanical Life

1 million operations

Construction

Glass fiber-reinforced polyamide thermoplastic hous-
ing; UL 94-V0 rating

Environmental Rating

IEC IP65
NOTE: Addition of a No. 3 x ¼" screw (max) to the wir-
ing access door increases sealing to IEC IP67, NEMA
4X

Operating Conditions

Temperature: -30° to +80° C (-22° to +176° F)

Weight

SI-QS75 models: 0.11 kg (0.25 lb)
SI-QS90 models: 0.13 kg (0.29 lb)

Application Notes

Certifications

Models with one and two contacts have three cable entry locations
(bottom and two sides); models with three contacts have two cable
entry locations (two sides). All entry locations are sealed with
knockouts. To remove knockouts, thread the supplied M16 x 1.5 or
M20 x 1.5 to ½"–14 NPT conduit adapter or optional M16 x 1.5 or
M20 x 1.5 cable gland into one of the threaded entry locations. The
knockout will break open just before the adapter or cable gland
bottoms out.
