Brandmotion 1008-6509-V2 User Manual
Brandmotion For the car

6509 Instructions 5-22-12 Flex.doc
1 of 9
Rear Vision System – Liftgate Emblem Camera for Aftermarket
Display
2009-2012 Ford Flex (Kit part number 1008-6509)
Kit Contents:
Tools Required:
Liftgate Emblem Mount with Camera
Chassis Harness with RCA (Note: In some cases a
RCA extension may be required to connect to
your aftermarket display.)
1 bag containing: Ford Emblem
1 bag containing:
2 Liftgate emblem retainers
2 Mounting Screws
1 bag containing:
25 Wire Ties (short)
Z-Tech (in a white bottle)
1 bag containing:
1 Template (along with these instructions)
5.5mm, 7mm, 8mm, and 10mm Sockets
Phillips Screwdriver
Plastic Trim Removal tool
Pliers
Razor Knife or scissors
Wire Cutters
Soldering Iron
Small Brush
Addtional Tools:
Drill Bit
1¾ inch Center Hole Saw
Flat Metal File
Round File or Deburring Tool
NOTE: We strive to provide accurate and up-to-date installation instructions. For the latest full color
instructions, as well as an installation video (use relevant portions of 1008-9520), please visit
www.brandmotion.com
PRE-INSTALLATION VEHICLE CHECKLIST
Before beginning, determine how the vehicle is equipped and check appropriate boxes:
Determine whether the vehicle has the required two mounting holes and a camera harness opening behind the existing
liftgate emblem. Refer to Steps 2-4 to remove inner liftgate panel, and use supplied 1008-9100-03 template to
confirm whether the required holes are present in the panel.
□
No, use supplied 1008-9100-03 template to position the holes to drill and/or cut the liftgate.
□
Yes, proceed to Section 2.
□
Check kit contents are complete against the list above.
TABLE OF CONTENTS
Pages
Section 1: Camera Mount Preparation
2-3
Section 2: Camera Installation
4
Section 3: Chassis Harness Installation
5-6
Section 4: Ignition, Reverse and Ground Locations
7-8
Section 5: Reference - Supplied Camera and Chassis Harness Pinouts
9
