2-22 Construct Your Starter Kit
The 1784-PCD is now a part of your network.
Remove the 1784-PCD Card
If you want to remove the card on most computers, you press the
release button and remove the card from the slot. If this is not
applicable to your computer, follow the instructions specified in the
card’s user manual
IMPORTANT
Be certain to install the required drivers for your
1784-PCD or RSLinx will not know to look for the
hardware when you go online with your network.
Refer to your 1784-PCD documentation for details.
1771-SDN,
1747-SDN, or
1756-DNB
probe
connection
micro to
conductor
cable
42034
20722-M
