1 Publication DNET-UM003A-EN-P - August 2000
Chapter
5
RSNetWorx for DeviceNet Starter Kit
Demonstration
What This Chapter Contains Read this chapter to use the RSNetWorx for DeviceNet demonstration
network files and ladder logic programs provided for your Starter Kit.
The following table describes what this chapter contains and where to
find specific information.
What Does the DeviceNet
Starter Kit Demonstration
Do? The sample RSNetWorx network file (.dnt) is the configuration of the
devices that are contained in your Starter Kit. The ladder logic
program (.rss, .rsp, .acd) provides a way for the devices to
communicate with the scanner and to perform basic functions or react
to a trigger.
The results of the network configuration and ladder logic are:
•
When you place your hand in front of the RightSight
Photoelectric Sensor the processor (the location of the ladder
logic) tells the scanner that the green ControlTower Stack Light
needs to illuminate. The scanner then signals the Stack Light to
illuminate.
•
When you place a metal object in front of the Inductive
Proximity Switch an analog value is sent to the processor (the
location of the ladder logic). The ladder logic monitors the
analog data and sends a message to the scanner to turn on the
CompactBlock outputs depending on the objects distance from
the Inductive Proximity Switch.
•
When you place a metal object directly on the Standard
Proximity Switch connected to the ArmorBlock MaXum I/O,
the processor sends a message to the scanner to tell the red
Stack Light to illuminate.
To: See page:
review what the demonstration does 5-1
determine what files to use with your Starter Kit 5-2
run the demonstration 5-3
monitor I/O data 5-8
