Publication DNET-UM003A-EN-P - August 2000
Before You Begin 1-3
The Hardware and
Software You Need for Your
Starter Kit The following tables list the materials you need in order to follow the
procedures described in this manual.
Become familiar with which products come with the DeviceNet Starter
Kits and which you must provide. A set of “base” products are
provided for use with your DeviceNet Starter Kit. The following
products are common to all seven SKITs:
r
14. Connect and node commission one device at a time.
a. CompactBlock I/O
b. ControlTower Stack Light
c. Inductive Proximity Switch
d. RightSight Photoelectric Sensor
r
15. Automap a scanlist, modify the scanlist and
download the configuration to the scanner or use
the .dnt file provided with your Starter Kit.
r
16. Edit the I/O Parameters for the Inductive Proximity
Switch to send a strobed signal vs. a cyclic signal.
r
17. Start RSLogix 5, 500, 5000 or other ladder logic
software.
r
18. Open the provided demonstration ladder logic, go
online and download the program to the processor.
r
19. Experiment with your network.
Table 1.A Follow these steps to set up your Starter Kit
Check Steps to follow:
Base products provided in the SKITS: Catalog Number:
DEMO VERSION, RSNetWorx™ for DeviceNet 9357-DNET-L3
RightSight Photoelectric Sensor 42EF-D1LDAK-F5
DeviceNet Inductive Proximity Switch 871TM-D5ED18-D5
CompactBlock I/O (8 In / 8 Out) 1791D-8B8P
ArmorBlock MaXum (4 In / 4 Out) 1792D-4BVT4D
ArmorBlock MaXum Base for Flat Media 1792D-CBFM
DeviceNet ControlTower Stack Light Base 855T-DM1BSB
Stack Light green 855T-B24DN3
Stack Light red 855T-B24DN4
Standard Proximity Switch 872C-D3NP8-D4
Termination Resistor for Flat Media (2) 1485A-T1H4
Probe Cable 1787-PCABL
Cable, micro 90 to conductor (2) 1485K-P1F5C
Sensor cable, works with ArmorBlock MaXum I/O 889D-F4ACDM-1
Cable, micro male to micro female (2) 1485K-P1F5-R5
Chapter 5
Chapter 4
