SAFETY MANUAL
D oc N umber T8094
I ssue 27 – June 2013
Page 65 of 103
will then take up the fail-safe (logic ‘0’) condition. This is not fault tolerant and
only becomes fail safe after the fault detection period or test interval. If the sum
of the TI, and 2× Tscan is not less than PST
E
, then an alternative I/O
architecture shall be chosen.
2. Guarded output modules provide a one-out-of-two (1-oo-2) structure within a
single module. A single fault may in an indeterminate condition on a redundant
output channel, leading to either immediate fail-safe action, or action by the
other channel on demand. A faulty output will be detected within the fault
detection period, and shall be replaced within the second fault occurrence period
to ensure continued functional safety. This provides a fail-safe output structure
and may be used within safety-related configurations.
3. Dual guarded outputs, this structure uses two guarded output modules in
parallel, i.e. a quad output structure. This structure is both fault-tolerant and fail-
safe. As with other dual structures, a failed output shall be replaced within the
second fault occurrence period to ensure continue safe operation.
TÜV Certified
Configuration
Conditions
Digital Inputs
T7401, 24 VDC
T7402, 48 VDC
T7404, 110 VAC
T7408, 120 VDC
1oo2
or
2oo3
or
1oo3
Normally energized (de-energize to trip): certified
only if the inputs are dynamically transitioned at a
period not greater than the second fault occurrence
time.
1oo3 configuration means that the 3 input signals
cannot be voted. Any mismatch of the signals leads
to an alarm annunciation.
Monitored Inputs
T7411, 24 VDC
T7411F, 24 VDC
T7418F, 120 VDC
1oo2
or
2oo3
Normally energized (de-energize to trip): certified
only if the inputs are dynamically transitioned at a
period not greater than the second fault occurrence
time.
Normally de-energized (energize to trip): certified
only for applications that fulfil the requirements
under section 3.2.4.
T7419, fire detector MooN
Analog Inputs
T7420A, standard
T7420AF, fast
response
2oo3 with mid-value
select
or
dual with high/low
select
Certified only if the inputs are dynamically ranged
over full scale at a period not greater than the
second fault occurrence time.
Other Inputs
T7431A,
thermocouple
Not safety related but
interference free
Certified as non-interfering and can be used for
non-safety-critical input devices.
Input and Output
Multiplexer
T7491
Not safety related but
interference free
Certified as non-interfering and can be used for
non-safety-critical input devices.
Table 11 - Input Module, Low Density I/O
