Trusted
TM
Toolset Suite T8082
Issue 14 Feb 10 PD-T8082 52
serial1=19200,8,Odd,1,rs485fdmux
serial2=19200,8,Odd,1,rs485fdmux
serial3=19200,8,Odd,1,rs485fdmux
serial4=19200,8,Odd,1,rs485fdmux
tcp_ip0=10.10.10.1,255.255.255.0,11.10.9.8
tcp_ip1=9.9.9.1,255.255.255.0,11.10.9.8
;
; Modbus slave settings
;
mb_port_timeout=300
;
; Trusted - Expander Chassis
;
; Chassis Number 2
;
;
[CHASSIS_02_SLOT_01]
module_type = 8403
description=TMR 24Vdc Digital Input
simulate= 0
scan_interval = 0
;
cli='DCB'
cli='DCL "[SYSTEM]"'
$[templates\system\sys.inc]
cli='DCL "[LED]"'
$[templates\Led\LED.inc]
cli='DCL "[THRESHOLD]"'
$[templates\threshold\Threshold.inc]
cli='DCE'
;
[CHASSIS_02_SLOT_02]
module_type = 8451
description=TMR 24Vdc Digital Output
simulate= 0
scan_interval = 0
;
cli='DCB'
cli='DCL "[SYSTEM]"'
$[templates\system\sys.inc]
cli='DCL "[LED]"'
$[templates\Led\LED.inc]
cli='DCE'
;
[VCI]
;
;VERSION CONTROL INFORMATION
;The variable is calculated on everything
;excluding the CRC line
;
Author = NickO
ProjectTitle = Demonstration File
Date = 18/06/2004
Time = 12:32:01
Note =
