6 IntelliCENTER Software
Publication MCC-UM001E-EN-P - March 2014
The known file extensions that are created/used by IntelliCENTER software are:
• .dwg (Drawing)
• .txt (Text Document)
• .wsp (Work Space File)
• .csv
• .png (PNG Image)
• .ldb (temporary database file)
• .tlb (TLB File)
• .acd (RSLogix/Studio 5000 Project)
• .L5X (L5X File)
• .InstallLog (INSTALLLOG File)
• .InstallState (INSTALLSTATE File)
Services IntelliCENTER Depends On
The services that IntelliCENTER depends on are:
• IntelliCENTER Communication Server
• RSLinx Classic
• Windows Event Log
Equipment Necessary for Connecting the Computer
This is the equipment you need to connect your computer through your network.
DeviceNet Network
For a DeviceNet network, you need the following equipment.
Laptop computer
1784-U2DN USB to DeviceNet cable
or 1784-PCD DeviceNet personal computer interface card and 1784-PCD1
cable
Desktop computer
1784-U2DN USB to DeviceNet cable
or 1784-PCID DeviceNet personal computer interface card
RS232 interface (reduced
performance)
1770-KFD module
TIP
A 2100H-ICPC120 patch cable is necessary for connecting interface (laptop, desktop, RS232) to IntelliCENTER MCC wireway.
