Troubleshooting the Drive

9-13

* Components are identified in figure 2.4.
** M/N 25G4160 and 25G4260
*** Replace the Gate Driver Board when the IGBT modules are replaced.

Table 9.4 – 15-25 HP Drive Replacement Parts

Description*

Part Number

Quantity per

Horsepower

15

20

25**

NEMA 1 Fan Assembly

615161–V

2

2

2

NEMA 4X/12 Fan Assembly

615161–S

2

2

2

NEMA 1 Cover

805547–1S

1

1

1

NEMA 12 Cover/Gasket

805547–2S

1

1

1

Membrane Switch Keypad/Top

Bracket

805548–1R

1

1

1

Regulator PCB

0–56921–6xx

1

1

1

IGBT Module

602909–813AW

3

3

3

Capacitor PCB

0–56961

0–56962

1

1

1

Power Board

0–56963

1

1

1

Power Supply Board

0–56950–15

0–56950–20

1

1

1

Gate Driver Board***

0–56960

1

1

1

Internal Fan Assembly

615159–1S

1

1

1
