3-10 GV3000/SE AC Drive Hardware Reference, Version 6.06
*Recommended fuse type: UL Class J, 600 V, time delay, or equivalent.
**The drive contains internal fusing sized to protect the drive. Install fuses to protect the input wiring in
accordance with local codes.
Table 3.12 – AC Input Line Fuse Selection Values
Drive
Model Number
Selected Regulation
and
Horsepower Rating
Input Voltage
(+/-10%)
Fuse
Rating*
1V4160 1V4460 V/Hz or Vector (1 HP) 380-460 VAC 6 A
2V4160 2V4460 V/Hz or Vector (2 HP) 380-460 VAC 8 A
3V4160 3V4460 V/Hz or Vector (3 HP) 380-460 VAC 12 A
5V4160 5V4460 V/Hz or Vector (5 HP) 380-460 VAC 20 A
7V4160 7V4260 V/Hz or Vector (7.5 HP) 380-460 VAC 25 A
10V4160 10V4260 V/Hz or Vector (10 HP) 380-460 VAC 35 A
15V4160 15V4260 V/Hz or Vector (15 HP) 380-460 VAC 45 A
20V4160 20V4260 V/Hz or Vector (20 HP) 380-460 VAC 60 A
25G4160 25G4260 V/Hz (25 HP) 380-460 VAC 70 A
25V4160 25V4260 V/Hz or Vector (25 HP) 380-460 VAC 70 A
30V4160 30V4260 V/Hz or Vector (30 HP) 380-460 VAC 100 A
40V4160 40V4260 V/Hz or Vector (40 HP) 380-460 VAC 100 A
50V4160 50V4260 V/Hz or Vector (50 HP) 380-460 VAC 125 A
50R4160 50T4160 Vector (50 HP) or
V/Hz (75 HP)
380-460 VAC 125 A
60G4160 60G4260 V/Hz (60 HP) 380-460 VAC 150 A
75R4160 75T4160 Vector (60-75 HP) or
V/Hz (100 HP)
380-460 VAC 125 A
150 A
125R4160 Vector (100-125 HP) or
V/Hz (125-150 HP)
380-460 VAC 250 A
200V4160 Vector (150-200 HP) or
V/Hz (200 HP)
380-460 VAC **
250V4160 V/Hz or Vector (250 HP) 380-460 VAC **
300V4160 V/Hz or Vector (300 HP) 380-460 VAC **
350V4160 V/Hz or Vector (350 HP) 380-460 VAC **
400V4160 V/Hz or Vector (400 HP) 380-460 VAC **
