2-2 GV3000/SE AC Drive Hardware Reference, Version 6.06
Table 2.1 – Power and NEMA Enclosure Ratings
Model
Number
Selected
Regulation 1 and
Horsepower
Rating
1 With V/Hz regulation, 110% continuous output current capability. With vector regulation, 150% output current capability for one minute.
NEMA
Rating
Input
KVA
Input
Amps 2
2 Input Voltage: 380-460 VAC (+/-10%)
Output
Amps
at
2 kHz
Output
Amps
at
4 kHz
Output
Amps
at
8 kHz
Power
Loss
Watts
(Full
Load)
1V4160
1V4460
V/Hz or Vector
(1 HP)
1
4X/12
2.0 2.5 2.1 2.1 2.1 60
2V4160
2V4460
V/Hz or Vector
(2 HP)
1
4X/12
3.3 4.2 3.4 3.4 3.4 100
3V4160
3V4460
V/Hz or Vector
(3 HP)
1
4X/12
5.1 6.4 5.3 5.3 5.3 140
5V4160
5V4460
V/Hz or Vector
(5 HP)
1
4X/12
7.9 9.9 8.2 8.2 8.2 180
7V4160
7V4260
V/Hz or Vector
(7.5 HP)
1
12
10.7 13.4 11.1 11.1 11.1 210
10V4160
10V4260
V/Hz or Vector
(10 HP)
1
12
13.4 16.8 14.2 14.2 14.2 250
15V4160
15V4260
V/Hz or Vector
(15 HP)
1
12
20.2 25.4 21.0 21.0 21.0 375
20V4160
20V4260
V/Hz or Vector
(20 HP)
1
12
26.1 32.7 27.0 27.0 27.0 600
25G4160
25G4260
V/Hz
(25 HP)
1
12
29.5 37.0 30.4 30.4 30.4 600
25V4160
25V4260
V/Hz or Vector
(25 HP)
1
12
30.2 38.0 34.5 34.5 34.5 750
30V4160
30V4260
V/Hz or Vector
(30 HP)
1
12
35.0 44.0 39.0 39.0 39.0 800
40V4160
40V4260
V/Hz or Vector
(40 HP)
1
12
46.2 58.0 54.0 54.0 54.0 960
50V4160
50V4260
V/Hz or Vector
(50 HP)
1
12
57.3 72.0 67.0 67.0 67.0 1200
50R4160
50T4160
Vector (50 HP) or
V/Hz (75 HP)
1 65.0
81.0
81.0
102
70.0
90.0
56.0
72.0
41.0
54.0
1420
60G4160
60G4260
V/Hz
(60 HP)
1
12
71.7 90.0 78.0 78.0 78.0 1200
75R4160
75T4160
Vector (60-75 HP)
or V/Hz (100 HP)
1 80.0
100
101
126
89.0
116
71.0
93.0
53.0
70.0
1400
1780
125R4160 Vector (100-125 HP)
or V/Hz (125-150 HP)
1 127
170
159
213
152
210
122
168
91.0
126
2410
3200
200V4160
200V4160DS 3
3 With optional input disconnect factory installed
Vector (150-200 HP)
or V/Hz (200 HP)
1A 224 281 240 240 - 3290
250V4160
250V1460DS 3
V/Hz or Vector
(250 HP)
1A 269 337 302 302 - 4160
300V4160
300V4160DS 3
V/Hz or Vector
(300 HP)
1A 310 389 361 361 - 5100
350V4160
350V4160DS 3
V/Hz or Vector
(350 HP)
1A 352 442 414 414 - 6150
400V4160
400V4160DS 3
V/Hz or Vector
(400 HP)
1A 394 494 477
477 4
4 110% overload only at 4KHz in V/Hz and vector modes.
- 7350
