Industrial Performance Monitors 33
Rockwell Automation Publication 6186M-IN002C-EN-P - December 2011
Specifications
Industrial Monitors - 1200M, 1500M, 1700M, 1900M
Attribute Specification 1200M models 1500M models 1700M models 1900M models
Display Type Color active matrix TFT
Touch screen description Resistive antiglare
Size (diagonal), approx. 307 mm (12.1 in.) 381 mm (15.0 in.) 432 mm (17.0 in.) 483 mm (19.0 in.)
Display area (W x H),
approx. 246 x 185 mm
(9.7 x 7.3 in.) 304 x 228 mm
(12 x 9 in.) 338 x 270 mm
(13.3 x 10.7 in.) 376 x 301 mm
(14.8 x 11.9 in.)
Resolution (native mode) 800 x 600
256 K colors 1024 x 768
16.2 M colors 1280 x 1024
16.7 M colors
Luminance (typical) 450 cd/m
2
(Nits) 350 cd/m
2
(Nits) 300 cd/m
2
(Nits)
Contrast ratio (typical) 1000:1 700:1 1000:1 1300:1
Response time (typical) <35 ms
Backlight CCFT Tubes; 50,000 h (for 1/2 brightness) at 25 °C (77 °F)
Electrical Input voltage, AC 100…240V AC, autoswitching
Line frequency 47…63 Hz
Power consumption, max. 34 W 55 W 57 W
Input voltage, DC 9…36V DC
Mechanical Dimensions (H x W x D),
approx. 260 x 340 x 61 mm
(10.24 x 13.39 x
2.4 in.) 309 x 410 x 61 mm
(12.15 x 16.11 x
2.4 in.) 356 x 452 x 61 mm
(14.03 x 17.81 x
2.4 in.) 399 x 483 x 64 mm
(15.7 x 19.0 x 2.52
in.)
Weight, approx.
Aluminum bezel
Stainless steel bezel 4.4 kg (9.75 lb)
— 7.3 kg (16 lb)
8.6 kg (19 lb) 0 8.6 kg (19 lb)
10.1 kg (22.25 lb)
10.2 kg (22.5 lb)
11.9 kg (26.25 lb)
Mounting options Panel
Bench/tabletop
Rack Bench/tabletop
Rack
Environ-
mental Temperature,
Operating
(1)
Non-operating
(1) At 40 °C (104 °F) operating temperature, the humidity must not exceed 90%. At 50 °C (122 °F) operating temperature, the
humidity must not exceed 50%. Operating the monitors beyond these limits for extended periods of time can reduce the life of
the product.
0…55 °C (32…131 °F)
-20…60 °C (-4…140 °F) 0…50 °C (32…122 °F)
-20…60 °C (-4…140 °F)
Relative humidity 10…90% without condensation
Vibration
(2)
(2) For operating and non-operating conditions.
2 g peak (10…640 Hz)
Shock
Operating
Non-operating 20 g (1/2 sine, 11 ms)
30 g (1/2 sine, 11 ms)
Enclosure ratings NEMA UL 50 Type 1, 4, 4X and 12, IEC IP66
