20 Industrial Performance Monitors

Rockwell Automation Publication 6186M-IN002C-EN-P - December 2011

1500M Aluminum Bezel

383.6 (15.10)

296 (11.65)

409.98 (16.14)

308

.9

8 (12.16

)

28

2.6 (11

.1

3)

5 (0.20)

28 (1.10)

50.80

(2.00)

60.55 (2.38)

199.5

0 (7

.85)
