Rack mounting, Mounting guidelines – Rockwell Automation 6186M-xxxx Industrial Performance Monitors Installation Instructions User Manual
Page 15
Industrial Performance Monitors 15
Rockwell Automation Publication 6186M-IN002C-EN-P - December 2011
Rack Mounting
You can install the 1200M, 1500M, and 1700M monitors directly into an EIA-rack cabinet by
using the appropriate rack adapters.
Mounting Guidelines
Observe these guidelines when installing the monitor in an EIA-rack cabinet:
•
The cabinet height must accommodate the monitor’s panel height.
•
The cabinet depth must accommodate the monitor’s depth plus rear clearance for cables
and airflow. A cabinet depth of 112 mm (4.4 in.) is sufficient.
Cat. No.
Description
6189V-MRA12
Rack adapter for 1200M monitor
6189V-MRA15
Rack adapter for 1500M monitor
6189V-MRA17
Rack adapter for 1700M monitor
