90 Rockwell Automation Publication 6000-IN006A-EN-P - April 2014
Appendix F Power Cabling and Control Signal Wiring Details
All of the AI/AO, DI/DO connection points are expandable based on user requirements.
VFD alarm indication (905, 906) 1 VFD-provided normally open passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD fault indication (907, 908) 1 VFD-provided normally open passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD operation indication (909, 910) 1 VFD-provided normally open passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD stop indication (911, 912) 1 VFD-provided normally closed passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD ready indication (913, 914) 1 VFD-provided normally closed passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
Remote DCS control indication (915, 916) 1 VFD-provided normally closed passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
13 VFD allow closing indication (135, 121) 1 VFD-provided normally closed active dry contact
(voltage class ≤220V AC, 5A) (spare)
Input circuit breaker closing indication (136,
121) 1 VFD-provided normally closed active dry contact
(voltage class ≤220V AC, 5A) (spare)
Input circuit breaker opening indication
(137, 121) 1 VFD-provided normally closed active dry contact
(voltage class ≤220V AC, 5A) (spare)
VFD alarm indication (138, 121) 1 VFD-provided normally open active dry contact
(voltage class ≤220V AC, 5A) (spare)
VFD fault indication (139, 121) 1 VFD-provided normally open active dry contact
(voltage class ≤220V AC, 5A) (spare)
VFD operation indication (140, 121) 1 VFD-provided normally open active dry contact
(voltage class ≤220V AC, 5A) (spare)
VFD stop indication (141, 121) 1 VFD-provided normally open active dry contact
(voltage class ≤220V AC, 5A) (spare)
VFD ready indication (142, 121) 1 VFD-provided normally open active dry contact
(voltage class ≤220V AC, 5A) (spare)
Spare (143, 121) 1 VFD-provided normally open active dry contact
(voltage class ≤220V AC, 5A) (spare)
Spare (120, 121) 1 VFD-provided 220V AC (load ≤10 W, spare)
Table 32 - I/O Connections related to Remote Distributed Control System (Continued)
Serial Number Name of I/O Connection AI AO DI DO Note
