Page 55: Chapter 4, Drive electrical interconnection, Introduction electrical interconnection summary, Chapter
Rockwell Automation Publication 6000-IN006A-EN-P - April 2014
55
Chapter
4
Drive Electrical Interconnection
Introduction
The drive is shipped in two sections, the Isolation Transformer cabinet and the
Power Module/LV Control cabinet. An optional bypass cabinet may also be
supplied. Chapter 2 describes mechanically joining these cabinets together. This
chapter describes the activities required to electrically connect these drive
cabinets’ components together (information about connecting the Bypass
cabinet to the drive is included in publication 6000-UM002_-EN-P, 6012DB
Medium Voltage Bypass Cabinet User Manual).
Electrical Interconnection
Summary
Connect Internal Cabling and Wiring
Page
Connect Isolation Transformer Secondary Power Cables
Connect Motor and Voltage Sensing Board Cables
