Rockwell Automation Publication 6000-IN006A-EN-P - April 2014 19
Shipping and Handling Procedures Chapter 1
Overhead Lifting
Methods The preferred method of lifting the cabinets is an overhead crane. If overhead
lifting with a crane is not available, use a fork lift with a capacity greater than the
cabinet weight. Lift the cabinet using the overhead lifting angles or isolation
transformer lifting provisions and suitable spreader bars and rigging attached to
the fork lift.
Lift the Power Module/LV
Control Cabinet Two lifting angles are used for the Power Module/LV Control Cabinet and are
affixed to either side of the shipping skid.
The length of the lifting angles depends on the length of the Power Module/LV
Control Cabinet.
Install the Lifting Angles
The lifting angles hold the Power Module/LV Control cabinets together to
prevent separation and damage while riggers move the drive to the final
installation area.
The lifting angles are shipped with the Power Module/LV Control Cabinet and
must be secured before lifting the cabinet.
1. Remove the lifting angles from the skid.
2. Remove the attachment hardware that is pre-installed in the mounting
holes in the cabinet top plate before shipment.
IMPORTANT Close and lock the cabinet doors before moving any cabinets.
Table 4 - Lifting Angles
Length, approx. Dimensions, approx. Weight per Angle, approx.
1.2 m (3.9 ft) 100 x 80 x 8 mm (3.9 x 3.1 x 0.32 in.) 13.1 kg (29 lb)
2.0 m (6.6 ft) 100 x 80 x 8 mm (3.9 x 3.1 x 0.32 in.) 21.9 kg (48 lb)
2.4 m (7.9 ft) 100 x 80 x 8 mm (3.9 x 3.1 x 0.32 in.) 26.3 kg (58 lb)
3.5 m (11.6 ft) 125 x 80 x 10 mm (4.9 x 3.1 x 0.39 in.) 54.6 kg (120 lb)
4.2 m (13.6 ft) 125 x 80 x 10 mm (4.9 x 3.1 x 0.39 in.) 64.1 kg (141 lb)
4.9 m (16.1 ft) 125 x 80 x 10 mm (4.9 x 3.1 x 0.39 in.) 75.8 kg (167 lb)
IMPORTANT Label and retain all lifting-related hardware if the drive system may be moved
in the future.
ATTENTION: Failure to install the pair of lifting angles prior to moving the drive
may result in personal injury and/or equipment damage.
