1 Publication 6185-UM006A-EN-P - July 2002
Appendix
D
Product Specifications
Display 6185-F
Type Compensated Thin Film Transistor (TFT) LCD
Backlight
Type
Life Expectancy Cold Cathode Tubes (CCT) (4 bulbs)
50,000 hours (mean for 1/2 brightness point)
Nominal Display Area
Diagonal
Horizontal
Vertical 15.0 in (382mm)
12.0 in (304mm)
9.0 in (228mm)
Luminance (typical without
screen shield) 250 Nits
CIE Coordinates (typical)
White X: 0.327
Y: 0.336
(+/- 0.060 -- exact coordinates are non-critical)
Contrast Ratio (typical) 300:1
Response Time < 25 msec (typical)
Video 6185-F
Resolution 1024x768xRGB (native mode), 16.7million colors
Supported Standards VGA 720x400 at 70Hz (IBM boot mode)
VESA 640x480 at 60/75Hz
VESA 800x600 at 60/75Hz
VESA 1024x768 at 60/70/75Hz
Video Bandwidth 80MHz (max. video dot clock)
Video Input Signal RGB analog (white level = 0.700V above ref. Black,
into 75 Ohms, single ended)
Sync InputSignals Separate Horizontal and Vertical Sync Control, TTL
signal levels
Input Connection Female HD-15, 5-BNC connector support through
cable adapter
OSD Controls and
Indicators 6185-F
Automatic Screen Setup, Brightness, Contrast,
Horizontal Position, Vertical Position, Image Lock,
Color Balance, and Video Information. Power On and
Sync detected.
