Rockwell Automation Publication 7000-UM201B-EN-P - June 2013 33
Drive Terminal Application Chapter 4
3. Enter the PIN (password) for the given level.
The PIN can be entered directly in the ‘Password’ input box or via the Soft
Keypad. If the correct PIN is entered, the “Current Access” will change to
the Access level requested.
4. Press OK.
Change the Access Password
The Access Filter dialog can also change the PIN associated with the Access
Level. PINs are stored within the drive, not the terminal application.
You must gain access to the PIN level you wish to change.
To change the PIN value:
1. Click Change.
2. Enter the new password into the field or via the Soft Keypad.
The new PIN must be re-entered into the next data entry field.
A status message indicates if the operation was successful.
Change the ReadWrite Filter
All parameters can be read, however only some can be written to.
To change the filter that is active:
• Touch or click the desired radio button ( Figure 29 ) and press OK.
Figure 29 - Parameter Filter
TIP Pressing the Logout push button will return the access level to the default
Access level at which no parameters can be modified.
