1Ć2
D IEEE 518 GUIDE FOR THE INSTALLATION OF ELECTRICAL
EQUIPMENT TO MINIMIZE ELECTRICAL NOISE
INPUTS TO CONTROLLERS FROM EXTERNAL
SOURCES
1.2 Related Hardware and Software
The Voltage Input module, M/N 61C542, contains the following:
1. One Voltage Input module
The following items must be purchased separately:
D Panel mount terminal board and cable assembly, M/N 61C547.
One is required per module.
or
D DIN rail mount terminal board and cable assembly, M/N 61C548.
One is required per module.
The Voltage Input module can be configured with the hardware
(purchased separately) listed in figure 1.1.
Host Model Number
AutoMate 30, 30E M/N 45C301, 45C305, 45C307
AutoMate 40X, 40, 40E M/N 45C409, 45C410, 45C411
DCS 5000 M/N 57C407
AutoMax M/N 57C430A, 57C431, 57C435
AutoMate Remote
I/O Processor
M/N 45C201B
DCS 5000/AutoMax Remote
I/O Communication Module
M/N 57C416
Figure 1.1 Ć Voltage Input Module Hardware Configuration
