CĆ1
Appendix C
Field Connections
TerminalBlock
Label
Voltage Input
Function
0A
0B
S
Voltage Circuit ă0: Analog Common
Voltage Circuit ă0: +10V Input
Voltage Circuit ă0: Cable Shield
S
1A
1B
Voltage Circuit ă1: Cable Shield
Voltage Circuit ă1: Analog Common
Voltage Circuit ă1: +10V Input
2A
2B
S
Voltage Circuit ă2: Analog Common
Voltage Circuit ă2: +10V Input
Voltage Circuit ă2: Cable Shield
S
3A
3B
Voltage Circuit ă3: Cable Shield
Voltage Circuit ă3: Analog Common
Voltage Circuit ă3: +10V Input
4A
4B
S
Voltage Circuit ă4: Analog Common
Voltage Circuit ă4: +10V Input
Voltage Circuit ă4: Cable Shield
S
5A
5B
Voltage Circuit ă5: Cable Shield
Voltage Circuit ă5: Analog Common
Voltage Circuit ă5: +10V Input
6A
6B
S
Voltage Circuit ă6: Analog Common
Voltage Circuit ă6: +10V Input
Voltage Circuit ă6: Cable Shield
S
7A
7B
Voltage Circuit ă7: Cable Shield
Voltage Circuit ă7: Analog Common
Voltage Circuit ă7: +10V Input
8A
8B
S
Voltage Circuit ă8: Analog Common
Voltage Circuit ă8: +10V Input
Voltage Circuit ă8: Cable Shield
S
9A
9B
Voltage Circuit ă9: Cable Shield
Voltage Circuit ă9: Analog Common
Voltage Circuit ă9: +10V Input
10A
10B
S
Voltage Circuit 10: Analog Common
Voltage Circuit 10: +10V Input
Voltage Circuit 10: Cable Shield
S
11A
11B
Voltage Circuit 11: Cable Shield
Voltage Circuit 11: Analog Common
Voltage Circuit 11: +10V Input
