Appendix a, Continued) – Rockwell Automation 61C346 4 Input 0-10V Analog Rail Module User Manual
Page 40
AĆ2
Appendix A
(Continued)
Input Channels
D Operating range: 0Ć10 VDC
D Number of channels: 4 (singleĆended)
D Number of commons: 1 (shared among all 4 channels)
D Resolution: 12 bits binary
D NonĆlinearity: + 1 LSB maximum
D Accuracy: +.33% of full scale at 25
o
C maximum
D Thermal drift: + 50 ppm/degree C
D Type of converter: Successive approximation
D Speed of conversion: 13 usec
D Impedance: 180K Ohm + 0.2%
D Input filter: 2nd order 160Hz low pass
D Input overvoltage protection: + 115 VDC continuous
D Isolation of analog section from host and input power: 2500V RMS
