Chapter
3
Communicate with Devices on an
Ethernet Network
This chapter explains how to communicate with a device on an Ethernet network
by using the SoftLogix controller.
For information about communicating with EtherNet/IP devices, see the
EtherNet/IP Network Configuration User Manual, publication
.
Configure Your System for an
Ethernet Network
For the SoftLogix controller to operate on an EtherNet/IP network, you need
the following:
• A computer where the SoftLogix controller resides enabled with an
Ethernet communication port
• RSLogix 5000 software installed
• A computer where the RSLogix 5000 software resides enabled with an
Ethernet communication port
• RSLinx software installed
You can use any commercially-available Ethernet port. Use the Ethernet driver
that comes with the device.
Topic
Page
Configure Your System for an Ethernet Network
Controller Connections over the EtherNet/IP Network
Example 1: Workstation Remotely Connected to a SoftLogix Controller
Example 2: Send Messages over the EtherNet/IP Network
Example 3: Send Messages over the EtherNet/IP Network to a PLC-5 Processor
